Product Description Product Description Crawler type hydraulic hammer Pile driver HWL300R Solar pile driver FOR Photovoltaic Power Station 3m hydraulic rotary press piling driver machine is multifunctional pile driving machine for mine, with 360 degrees of freedom to rotate, multi angle pile function. The machine with diesel powered, hydraulic mechanical transmission, with high efficiency, convenient shift, multi angle multi angle pile, high precision, durable, time-saving, labor-saving and, especially for engineering construction in the field. Technical Parameter Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station

Model	HWL300R
Hammer impact	780J
Pile length	0-3000mm
Duplex gear pump pressure	20Mpa
Duplex gear pump displacement	40ml/r
Hydraulic system pressure	20Mpa
Main valve flow	120L/M
Overall Machine weight	5.8T
Diesel engine power	80Kw
Rated Speed	2400R/min
Starting Voltage	24v
Rotation semi diameter(rotating shaft to Pod distance)	1925mm
Effective press pile stroke	0-3000mm
Dimension(LXWXH)	4600*2150*2800mm
Track shoe	350mm
Walking motor total displacement	1575ml/m
Walking motor rated pressure	18Mpa
Walking motor output torque	4300N.M
Walking motor rotate speed	50r/min
Press Pile Diameter	0-600mm
Drilling Depth	0-3000mm
Operating Speed (m/min)	90s/per pile
Number of impacts / strokes per 1 minute	900times/min
Maximum length of Piles to be rammed	3M
Walking speed	5-10Km/hr
Gradeability	0-35°
Oil tank capacity	200L
Hydraulic tank capacity (L)	500L

Products Details Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Full hydraulic rotary press piling machine by R & D engineers and field service member composed of hypercoagulable cohesion, high-quality elite team of engineers, according to the situation of equipment used in various kinds of working conditions of practice, through constant revision and improvement to under various complex site and all kinds of soil in a state of the equipment. Can be adapted to round pile, square pile, rectangular pile and various special-shaped pile. Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Related Model Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Recommended by sellerWheels mounted high diameter drill rig piling pile driver machine with CE certification$26,200.00 - $27,600.00 / Set1 SetSolar power system mini pile driver guardrail installation hydraulic pile driver equipment$23,600.00 - $27,580.00 / Set1 SetPhotovoltaic Solar Ground Construction piling rig machine bored pile hydraulic rig price$55,400.00 - $58,000.00 / Set1 SetGround Loader mounted Guardrail pile driver vibrating post driver in pile foundation$10,200.00 - $11,060.00 / Set1 Set Company Profile Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Construcation Site Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Contact Us Crawler type hydraulic hammer pile driver HWL300R Solar Pile Driver FOR Photovoltaic Power Station Contact me: Lily song Mobile: 0086-13583717630Whatsapp/wechat: 0086-13583717630Email: hw005(at)chinahwgroup.com

Contact us if you need more details on Crawler Type Hydraulic Hammer Pile Driver. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Hwl300r Solar Pile Driver For Photovoltaic、Vibratory Hammer Pile Driver. If these products fail to match your need, please contact us and we would like to provide relevant information.
